Zeroplus Technology ventures into PC-based Logic Analyzers market since 2005. PC-based logic analyzers enable the interpretation work of digital information becomes easier and more affordable. Zeroplus is considered one of the pioneers in PC-based logic analyzers market, and throughout all these years they have managed to produce several award winning series. The products come with two years warranty.
| Logic Analyzer Series |
Clock |
Trigger Channel |
Memory |
Memory Depth/Channel |
| LAP-C(322000) |
100Hz – 200MHz |
32 CH |
64 Mbits |
2 Mbits |
| LAP-C(32128) |
100Hz – 200MHz |
32 CH |
4 Mbits |
128 Kbits |
| LAP-C(162000) |
100Hz – 200MHz |
16 CH |
64 Mbits |
2 Mbits |
| LAP-C(16128) |
100Hz – 200MHz |
16 CH |
4 Mbits |
128 Kbits |
| LAP-C(16064) |
100Hz – 100MHz |
16 CH |
1 Mbits |
64 Kbits |
All logic analyzers above come with 24 sets of free protocol module that you can use for free.
| No . |
Protocol Analyzers Modules |
No. |
Protocol Analyzers Modules |
| 1 |
1-WIRE |
13 |
UART |
| 2 |
CAN 2.0B |
14 |
SPI |
| 3 |
IRDA |
15 |
7-SEGMENT LED |
| 4 |
3-WIRE |
16 |
USB 1.1 |
| 5 |
JTAG 2.0 |
17 |
LCD 1602 |
| 6 |
PS/2 |
18 |
DIGITAL LOGIC |
| 7 |
I2C(EEPROM 24LCS61/24LCS62) |
19 |
ARITHMETICAL LOGIC |
| 8 |
SSI Interface |
20 |
MICROWIRE |
| 9 |
MANCHESTER |
21 |
I2C(EEPROM 24L) |
| 10 |
MILLER |
22 |
UP DOWN COUNTER |
| 11 |
SPI(EEPROM AT25F) |
23 |
MICROWIRE(EEPROM 93C) |
| 12 |
I2C |
24 |
MCU-51
(only support 32 channel series) |
The long list of protocol analyzers available can be found here.
|
